D7 PRO multi-beam driving light housing with modular X-Lens system

After two years of development, we're excited to introduce the most powerful and feature-rich 4" driving light ever to hit the market! Ever wonder what 23,000 lumens does to a dark landscape? It'll blow your mind, and we haven't even started yet.

Imagine the most powerful driving light ever built, then add a flood beam, a spot beam and a hybrid beam, a multi-color daytime running light mode, two fully dimmable circuits and the option to change the beam shape and color on the fly. This is the D7 PRO , and it looks even better than it sounds.

The D7 PRO features a split dual circuit design that allows for completely independent on/off and dimming of a center flood beam and an outer spot beam. Use our revolutionary DialDim switch or CANsmart controller to effortlessly control all lighting functions from a single halo dimmer switch or the vehicle's OEM handlebar controls.

Add to that our patent pending X-Lens system, which allows you to change the color of the Center Flood or DRL beam to white, amber or selective yellow in an instant, giving the driver more flexibility and functionality than ever before.

Last but not least, the D7 PRO features a "DRL Boost Mode" that allows you to operate the center optic as a dimmed daytime running light or crank it up to 100% to create a powerful flood beam. Combined with the amber X-lenses, the innovative center optic can also flash in sync with your turn signals.

D7 PRO Pod Features

• HiDrive LEDS 11,900 lumens per pod – Seven 14-watt LEDs combined with our proprietary TIR optics make this the brightest light under 4.5 inches ever released
• Dual beam technology – Independent control (and dimming) of the central flood beam, the outer spot beam or the all-on hybrid beam
• Modular Snap-On X-Lens – Allows you to customize the beam shape and color in an instant. Interchangeable color of the central flood beam in white, amber or selective yellow
• DRL Boost Mode – Operate the center LEDs as a low intensity daytime running light or increase the power to create a massive high intensity flood beam
• Integrated indicator mode – Operate the center flood optic as an amber daytime running light or flood light that flashes in sync with the vehicle’s turn signals
• CANsmart and DialDim compatible – Control both circuits with a single DialDim switch or unlock over 20 functions and settings with the CANsmart Accessory Manager

D7 PRO Specifications (Single Pod)

• LEDs: (7x) 14 Watt Cree XML3
• Power consumption: 98 watts / 8 amps
• Raw lumens: 11,900
• Spot beam distance: 1250 feet (380 meters)
• Flood beam width: 250 feet (75 meters)
• DataDim™ compatible: Yes
• Operating voltage: 9–32 VDC
• Pod size: 11.2 cm round x 7.3 cm deep
• Pod weight: 1.8 pounds
• IP68 and 69K waterproof, submersible and high pressure spray
• E-mark approved spot lens (ECE R112 high beam)



D7 PRO Light Pod (DNL.D7P.050) includes:

• (1x) D7 PRO Light Pod (with mounting material)

• (3x) X-lenses (clear, amber and selective yellow)
• (1x) 2-in-1 single circuit wiring adapter
